Functional Principle, Technical Data
3.3

Technical Data

Model
Max. reach
Smallest measurable
object
Repeatability
Optical filters
Power supply
Alternating/
constant light
Ambient light
Power consumption
LLS
LLS8 LLS12
30 m (depending on aperture)
typ. 1 % of the Analog typ. 2 % of the aperture size,
aperture size Digital typ. 1 % of the aperture size
typ. 1 % of the Analog typ. 2 % of the aperture size,
aperture size Digital typ. 1 % of the aperture size
+24 VDC (± 10 %), reverse polarity protection, overload-proof
Alternating light Constant light
(100 kHz)
up to 5000 lux (depending on aperture)
Transmitter: typ. 50 mA
Receiver: typ. 30 mA
LLS12-HS LLS18
70 m
(depending on
aperture)
Depending on the
aperture size: Ana-
log typ. 0.5 % to
2 % of the aperture
size, Digital typ.
0.2 % to 1 % of the
aperture size
Depending on the
aperture size: Ana-
log typ. 0.5 % to
2 % of the aperture
size, Digital typ.
0.2 % to 1 % of the
aperture size
Interference filter
Constant light Alternating light
(45 kHz)
up to 5000 lux
Transmitter:
typ. 50 mA
Receiver:
typ. 40 mA
LLS90
100 m
(depending on
aperture)
typ. 1 % of the aper-
ture size
typ. 1 % of the aper-
ture size
Alternating light
(100 kHz)
up to 5000 lux
(depending on
aperture)
Transmitter:
typ. 60 mA
Receiver:
typ. 30 mA
Page 35
