Assembly

5.
The sensors of the LLS series are optical systems that operate in the millimeter range.
i
5.1
Mount the sensor only to the intended places depending on the respective model using screw or thread
fastening on a flat surface. Clamps of any kind are not permitted.
> Inaccurate, erroneous measurement values.
LLS
Assembly
Pay attention to careful handling during mounting and operation of the sensor.Sensor

Sensor Mounting

Ensure exact alignment of the light source and the receiver to one another during assembly. Adjust the
light curtain exactly to the receiver aperture.
