Lls18 - MICRO-EPSILON LLS series Betriebsanleitung

Operation
6.3.3
Pin Signal
1
2
3
4
4
4
Abb. 23 Receiver npn dark switching, pnp light switching
Pin Signal
1
2
3
4
Abb. 24 Receiver pnp dark switching, pnp light switching
Pin Signal
1
2
3
4
Abb. 25 Light source
Mounting bracket and connection cable:
Article 11251150
Article 11241120
Article 11241189
LLS

LLS18

+24 VDC (±10 %)
Analog (0 V ... +10 V)
GND (0 V)
OUTPUT
OUTPUT Q
pnp light switching
OUTPUT Qinv
pnp light switching
+24 VDC (±10 %)
ANALOG (0 ...+10 V)
GND (0 V)
OUTPUT INV
+24 VDC (± 10 %)
I-CONTROL (0 ... +24 V)
GND (0 V)
Shield - Housing
M18 mounting bracket
Connection cable 4-pole, M12, PNP , LED, plug angled, 2 m
Connection cable M12; 4-pole; PNP; 5 m angled, LED
Color
brown
4
white
blue
1
black
black HS
4-pole M12 plug
black HS
Color
brown
white
blue
black
Color
brown
white
blue
black
3
2
Page 47
