3. Setting up

3.1 Principes de base pour le montage de la caténaire Märklin
The following examples introduce several basic principles for
the Märklin H0 catenary, which you must pay attention
to when planning and setting up the catenary.
3.1.1 Installing the Catenary Wire
on a Mast
Important:
On a permanent layout reliability
is increased when the hanger
eyelets for the catenary wires
are closed with a pair of needle
nose pliers.
3.1.2 Maximum Deviation of the Catenary Wire from the Center Position:
6 mm / 1/4"
6
Important:
Maintaining this limit can be checked easily with the mast positioning jig set.
3.1.3 Using the 70231 Catenary Wire Adjustment Section
a. Separation of the catenary wire (only possible on the straight part)
6
6
23
