INVENTOR V5MKI32-18WiFiR/U5MRS32-18 Installationshandbuch Seite 15

Split Type Outdoor Unit
(Refer to Fig 5.4,5.5,5.6,5.10 and Table 5.1)
Fig. 5.4
Fig. 5.5
D
Fig. 5.6
Table 5.1: Length Specifications of Split
Type Outdoor Unit (unit: mm/inch)
Outdoor Unit Dimensions
WxHxD
760x590x285 (29.9x23.2x11.2)
810x558x310 (31.9x22x12.2)
845x700x320 (33.27x27.5x12.6)
900x860x315 (35.4x33.85x12.4)
945x810x395 (37.2x31.9x15.55)
990x965x345 (38.98x38x13.58)
938x1369x392 (36.93x53.9x15.43)
900x1170x350 (35.4x46x13.8)
800x554x333 (31.5x21.8x13.1)
845x702x363 (33.27x27.6x14.3)
946x810x420 (37.24x31.9x16.53)
946x810x410 (37.24x31.9x16.14)
952x1333x410 (37.5x52.5x16.14)
952x1333x415 (37.5x52.5x16.34)
H
W
W
Mounting Dimensions
Distance A
530 (20.85)
549(21.6)
560 (22)
590 (23.2)
640 (25.2)
624 (24.58)
634 (24.96)
590 (23.2)
514(20.24)
540(21.26)
673 (26.5)
673 (26.5)
634 (24.96)
634 (24.96)
Vertical Discharge Type Outdoor Unit
(Refer to Fig 5.7,5.8,5.9 and Table 5.2)
Fig. 5.7
H
Fig. 5.8
B
>30cm/11.8"
Distance B
290 (11.4)
325 (12.8)
335 (13.2)
333 (13.1)
Table 5.2: Length Specifications of Vertical
405 (15.95)
Discharge Outdoor Unit (unit: mm/inch)
366 (14.4)
404(15.9)
MODEL
378 (14.88)
340 (13.39)
18
350 (13.8)
24
403 (15.87)
36
36
403 (15.87)
48
404 (15.9)
60
404 (15.9)
(Wall or obstacle)
Air inlet
>120cm / 4.7"
W
(Wall or obstacle)
>30cm/11.8"
Air inlet
Air inlet
>30cm/11.8"
Air inlet
Fig. 5.9
DIMENSIONS
W
554/21.8
554/21.8
554/21.8
600/23.6
710/28
710/28
H
W
>30cm/11.8"
Air inlet
H D
633/25 554/21.8
633/25 554/21.8
759/29.8 554/21.8
633/25 600/23.6
759/29.8 710/28
843/33 710/28
