Siemens pointek CLS 200 Kurzanleitung Seite 8

P1
+
delay
L2
relay contact
8 A @ 250 V AC
5 A @ 30 V DC
Note: Switch and potentiometer settings are for illustration purposes only.
Relay Output Connection and Solid-state Switch Connection
K2 The relay is shown
in a de-energized
3 2 1
state.
NC
NO
COM
K2 contact ratings:
• 8 A at 250 V AC
• 5 A at 30 V DC
Diode Protection
customer-supplied
diode protection
Switch capacity:
Page EN-6 Pointek CLS 200 (analog) – QUICK START MANUAL
switch bank
K1
ON
2
3
1 2 3 4 5
sensor
L1
sensor
status
output
status
NO
NC
K2
3 2 1
K3
2 1
K3 contact ratings:
• 250 V AC, 100 mA max., non-polarized (max. 2 VA)
• 300 V DC, 100 mA max, non-polarized (max. 2 VA)
relay coil
250 V AC, 100 mA max., 2 VA/2 W max.
300 V DC, 100 mA max., 2 VA/2 W max
trip
point
+
P2
GND
K4
1
L3
power
3 2
on
power supply
12–250 V AC/DC
NO
K3
2 1
Solid-state switch to customer's control
or instrumentation device.
The switch is shown in de-energized state.
relay coil
customer-supplied
diode protection
removable
terminal
block (not
polarity
sensitive)
1
solid-state switch
100 mA @ 250 V AC
100 mA @ 300 V DC
max. 2 VA
7ML19985QE81
