Logical Level
Inversion
OFF
OFF
Status
• the usability of the measured value in the user program
• the device status (self-diagnosis/system diagnosis)
• additional process information (process alarms)
Please see the full manual for tables listing the codes for the Status byte.
Configuring the user data
Notes:
• To configure STEP 7, use HW-Konfig.
• To configure STEP 5, use COM_PROFIBUS.
The Discrete input function block supplies the content of the OUT parameter.
Diagnosis
Pointek CLS 200 can actively report information on its own status. Please see the full manual
for a list of diagnostic messages.
Remote Operation via PROFIBUS PA
To use PROFIBUS PA, you will need a PC configuration tool: we recommend SIMATIC PDM. You
can download an application guide from the product page at www.siemens.com/milltronics.
Also see the proprietary operating instructions or online help for details.
Functions
Open the device menu (top left side of screen) for access to the following functions: upload
from/download to the device; set address; master reset; write locking; sensor test via
PROFIBUS PA; and simulation.
Changing parameter settings
• First launch SIMATIC PDM, connect to Pointek CLS 200, and upload data from the device.
• Adjust parameter values in the parameter view field (right side of screen).
• When you have completed the adjustments, open the Device menu, download data to the
device, then save parameter settings offline.
• Go to View – Display to track the effects.
7ML19985QE81 Pointek CLS 200 (PROFIBUS PA) – QUICK START MANUAL
Sensor Status
uncovered
covered
Logical Level
= 0 (zero)
= 1
Page EN-17
