Installations, repairs and maintenance on the electrical in-
stallation may be carried out by an expert only.
Important notices
If there is a motor overload, it will turn off automatically.
After a cool-down period (timing varies), the motor can be
turned on again.
Operating instructions
You must observe the following points before commis-
sioning the double-ended bench grinder:
• Activate the main switch. Wait until the grinding wheel
has reached its maximum speed. Then you can start
grinding.
• Hold the work piece firmly on the tool rest and move it
slowly and steadily towards the grinding wheel.
• Grinding can lower the speed of the grinding wheel.
Reduce the pressure a little until the wheel has re-
turned to its full speed.
WARNING:
• Small work pieces should be held with pliers or a simi-
lar tool.
• Only ever grind on the face of the grinding wheel, never
on the sides.
• As most materials get hot during grinding, you must be
very careful with the work piece.
Working with the wet grinder
1 Put water into the water container.
2 Turn the machine on and leave it running until the grind-
ing wheel is completely wet.
3 Grind the tool.
4 Empty the water container after grinding. The drain plug
is located underneath the water container.
Note! If the grinding wheel has been in the water for a
lengthy period, distortion can occur and the grinding
wheel may no longer rotate smoothly.
Replacing the grinding wheel
WARNING: : In order to prevent injury by accidentally
starting the double-ended bench grinder, the device must
be turned off before replacing the grinding wheel (switch
position „0") and the power plug disconnected from the
socket.
• Loosen the spark protection and safety screen and pull
them out as much as possible but do not remove them.
• Loosen the tool rest and pull it out as much as possible.
• Remove the screws and pull off the end plate.
• Remove the outer flange and the old grinding wheel,
then attach the new grinding wheel.
Note:
• Do not remove the cardboard discs attached to the
sides of the new grinding wheel because they aid the
secure grip of the flange against the grinding wheel.
• Check the new grinding wheel for cracks or other vis-
ible damage and dispose of it if applicable.
• Re-attach the flange and nut.
• Do not tighten the nut too much with a spanner be-
cause the grinding wheel may break.
• Attach the end plate again.
• Adjust the tool rest, spark protection and safety screen
again according to the assembly instructions.
• Never sharpen or grind anything made of aluminum.
• Never sharpen or grind anything which cannot be held
correctly because of the size.
Replacing the wet grinder wheel (Fg. 5)
1 Drain the water (A).
2 Loosen the 2 cross-head screws (B).
3 Loosen the hex-nut (C).
4 Push the guard up and remove it.
5 Loosen the hex-nut, remove the flange and grinding
wheel (D), attach the new grinding wheel and secure
it again. Re-attach the guard.
m Intended use
The machine complies with the relevant EC Machine
Guideline.
• The manufacturer's stipulations concerning safety,
work and maintenance as well as the measurements
specified in Technical data, must be complied with.
• The relevant accident prevention stipulations and other
widely recognised safety rules must be observed.
• The machine may only be used, maintained or repaired
by expert personnel who are familiar with it and its dan-
gers. Unauthorised changes to the machine negate the
manufacturer's liability for damages resulting from this.
• The machine may only be used with the manufactur-
er's original accessories and original tools.
• Every use beyond that is deemed as not intended. The
manufacturer is not liable for damage resulting from
this; the risk lies exclusively with the user.
• Please note that our equipment has not been designed
for use in commercial, trade or industrial applications.
Our warranty will be voided if the equipment is used in
commercial, trade or industrial businesses or for equiv-
alent purposes.
m Residual risks
The machine has been built according to the latest
technology and recognised safety rules. However,
there is still a chance of residual risks whilst working.
• Risk of injury to fingers and hands from the rotating
grinding wheel during incorrect handling or placing of
the work piece to be ground.
• Risk of injury from ejected work pieces during incorrect
clamping or handling.
• Electrical hazards when unsuitable electric connec-
tions are used.
• Furthermore, despite all measures taken, residual risks
can occur that are not obvious.
• Residual risks can be minimised by complying with the
safety notices and the intended use as well as the
operating instructions overall.
m Transport
m Unplug the machine!
Carry the equipment by the left and right grinding wheel
cover.
When reassembling the equipment proceed as described
under section "Assembly", if necessary.
english 23
