Important hint in case of sending the equipment to a service station:
Due to security reasons please see to it that the equipment is sent back free of oil and gas!
Problem
Engine fails to start.
Engine runs errati-
cally.
Engine overheats.
Power Sweeper does
not sweep while en-
gine is running.
Power Sweeper does
not drive along.
Excessive vibration
22
Trouble Shooting
Cause
1. Spark plug wire disconnected.
2. Out of fuel or stale fuel.
3. Choke not in open position.
4. Blocked fuel line.
5. Fouled spark plug.
6. Engine flooding.
1. Spark plug wire loose.
2. Unit running on CHOKE.
3. Blocked fuel line or stale fuel.
4. Vent plugged.
5. Water or dirt in fuel system.
6. Dirty air cleaner.
7. Improper carburetor adjustment.
1. Engine oil level low.
2. Dirty air cleaner.
3. Air flow restricted.
4. Carburetor not adjusted properly.
1. The brush is blocked by the dirt and
debris.
2. Belt slack or worn.
3. The left upper lever loosen or worn.
1. Coupling cable for drive system not ad-
justed correctly.
2. Belt slack or worn.
3. Tire worn.
Loose parts or damaged worm.
Remedy
1. Attach spark plug wire securely to spark
plug.
2. Fill with clean, fresh gasoline.
3. Throttle must be positioned at choke for
a cold start.
4. Clean the fuel line.
5. Clean, adjust gap, or replace.
6. Wait a few minutes to restart, but do not
prime.
1. Connect and tighten spark plug wire.
2. Move choke lever to OFF.
3. Clean fuel line. Fill tank with clean, fresh
gasoline.
4. Clear vent.
5. Drain fuel tank. Refill with fresh fuel.
6. Clean or replace air cleaner.
7. Contact Service.
1. Fill crankcase with proper oil.
2. Clean air cleaner.
3. Remove housing and clean.
4. Contact Service.
1. Stop engine and pull off the spark plug,
and then remove the dirt and debris.
2. Have slack belt tightened. Have worn
belt replaced.
3. Have loosen lever tightened. Have worn
lever replaced.
1. Adjust coupling cable.
2. Have slack belt tightened. Have worn
belt replaced.
3. Have worn tire replaced.
Stop engine and pull off the spark plug,
and then tighten loose bolts and nuts and
have damaged worm repaired.
