1. GENERAL CHARACTERISTICS
– Air pressure: .......................................................................... 3 ÷ 6 bar (60 - 120 psi)
– Max hydraulic pressure: ....................................................... 700 bar (10,000 psi)
– Oil supply: .............................................................................. 0,5 l/min (0.13 gpm)
– Dimensions: width (A) .......................................................... 220 mm (8.7 in.)
– Weight (complete with high pressure hose and pedal): .......... 15 kg
– High pressure flexible hose: length ...................................... 3 m
– Oil reservoir capacity: ........................................................... 900 cm
– Recommended oil: .............................. AGIP ARNICA 32
– Coupler: the pump is supplied with a flexible, high pressure hose, compete with a
"quick-lock" female coupler, suitable for connection to a Cembre hydraulic crimping or
cutting head (see Fig. 2).
– Safety: the pump is provided with max pressure valve; MPC 1 special manometer is
available as an accessory to check the correct setting of the valve.
0
Acoustic Noise
(Directive 2006/42/EC, annexe 1, point 1.7.4.2 letter u)
– The weighted continuous acoustic pressure level equivalent
A at the work place L
– The maximum value of the weighted acoustic displacement
pressure C at the work place L
– The acoustic power level emitted by the machine
L
WA
25
PNEUMO-HYDRAULIC PUMP
15
CPP-1
(Ref. to Fig. 1)
Hydraulic pressure v. air pressure
800
16
700
600
17
500
●
●
400
18
●
300
3.0
3.5
4.0
19
Air pressure (bar)
20
depth (B) .......................................................... 220 mm (8.7 in.)
height (C) .......................................................... 350 mm (13.8 in.)
21
SHELL TELLUS OIL TX 32
22
23
24
25
is equal to .............................................................. 59,2 dB (A)
pA
is ..................................................... < 130 dB (C)
pCPeak
is equal to ............................................................................................. 69,5 dB (A)
2
ENGLISH
●
●
●
●
4.5
5.0
5.5
6.0
(26.5 lbs)
(10 ft)
(0.24 US gal.)
3
or
or equivalent
