1.6

Product description

This manual describes the installation or replacement of encoder interface cards in unit ver-
sion COMBIVERT F5 with safety function STO.
Attention
Only combinations released by KEB are permissible for replacement or installation of en-
coder interfaces.
The manual must be made available to any user who is responsible for the installation or
replacement of encoder interfaces.
Warning
The functionality of the drive/servo can change by installation, alteration or replacement of
encoder interfaces. The functionality is dependent on the setting/programming by the ma-
chine manufacturer.
COMBIVERT F5 with safety function is marked in the material number in the fifth position with
the letters K, L or P:
• xxF5Kxx-xxxx
• xxF5Lxx-xxxx
• xxF5Pxx-xxxx
Additionally a „FS" symbol must be printed on the type plate.
The connection and the settings of the inverter/servos are dependent on the encoder inter-
face type.
Info
Encoder interfaces are not safety components and they can be changed/installed without
anew safety test. No electrical connections between carrier board (control board) and power
unit may be opened during installation.
Permissible combinations
New or modified functionality
Encoder interfaces are not safety components
Preface
GB -7
