OPERATING
GB

SETTING UP THE INSTRUMENT

The instrument is set by a dip-switch. For configuration of the group, and to set half power priority for the desi-
red battery charger and the CAN termination, refer to the table given below.
SWITCH 1
OFF
OFF
ON
SWITCH 3
OFF
ON
SWITCH 4
OFF
ON
SWITCH 5
OFF
ON
SWITCH 6
OFF
ON
16
SWITCH 2
OFF
ON
OFF
FUNCTION
1
PRIORITY DEACTIVATED
1
PRIORITY ACTIVATED
FUNCTION
2
PRIORITY DEACTIVATED
2
PRIORITY ACTIVATED
FUNCTION
3
PRIORITY DEACTIVATED
3
PRIORITY ACTIVATED
FUNCTION
CAN TERMINATOR DEACTIVATED
CAN TERMINATOR ACTIVATED
FUNCTION
A
GROUP
B
GROUP
C
GROUP
DESCRIPTION
ON
1 2 3 4 5 6
ON
1 2 3 4 5 6
ON
1 2 3 4 5 6
DESCRIPTION
ON
1 2 3 4 5 6
ON
1 2 3 4 5 6
DESCRIPTION
ON
1 2 3 4 5 6
ON
1 2 3 4 5 6
DESCRIPTION
ON
1 2 3 4 5 6
ON
1 2 3 4 5 6
DESCRIPTION
ON
1 2 3 4 5 6
ON
1 2 3 4 5 6
RCM 1620 - REV003A
