Technical data

Determined on the basis of EN 14511 or Truma test conditions
Power supply
230 V – 240 V , 50 Hz
Power consumption
Cooling: 2.8 A
Starting current
20 A (150 ms)
Cooling power
1.7 kW (T35 / T35)
Air volume flow
max. 370 m³/h
Usage limits
+16 °C to 40 °C
Maximum angle during operation
8 %
Weight
27.5 kg plus installation materials
Dimensions (W x H x D)
External: 560 x 265 x 785 mm
Internal: 523 x 46 x 670 mm (air distributor)
Internal: 496 x 46 x 556 mm (air distributor small)
Refrigerant
R 407C / 0.36 kg
Contains fluorinated greenhouse gases covered by the Kyoto
Protocol. Hermetically sealed.
Global Warming Potential (GWP)
1774
CO2 equivalent
638.6 kg
Subject to technical changes.

Installation dimensions (in mm)

Figure 8
192
(212)
310
Figure 9
*
air distributor small
785
670
556*
400
(380)

Clearance around the air conditioning system

The clearance around the external unit must be 20 mm at
the front and 50 mm at the side. At least 20 mm of clearance
must be left at the rear. Truma recommends clearance of
50 mm so that the exhaust air can blow out freely.
Figure 10
The clearance around the air distributor must allow the air
to blow out without obstructions. The side clearance must be
at least 40 mm (not in the case of the air distributor small).
The pivoting range of flaps and doors must be taken into
consideration.
Figure 11 – Air distributor
Figure 11 a – air distributor small

Air inlets / outlets

Figure 12
