Figure 9 SAN data and management connections, single controller
Mac
A two-path connection, as shown above, is the minimum requirement for VTrak.
Task 3: Making Management and Data Connections
Management
cables
FC data cables
Fibre Channel Switch
Mgmt
UPS
FC 1 FC 2
4 4
2 2
1 1
Gb/s Gb/s
115200
8 N 1
13
Ethernet Switch
VTrak
