How to access a particular computer by using the On-Screen Display:
1. Press Ctrl+Num (standard) to open the On-Screen Display.
2. Use the Arrow keys
NOTE:
The On-Screen Display closes after the switching. An information dis-
play shows the active channel.
NOTE: If you leave the menu by pressing

Accessing computers by using key combinations

You can access a computer by pressing a key combination at the console keyboard.
For accessing a computer with a key combination, you do not need to open the On-
Screen Display. Switching by using a key combination is therefore the fastest way to
switch between channels.
How to access a particular computer by using key combinations:
1. Press the Hotkey+Select Key
In the default configuration, you can switch the channel by pressing
select keys to .
1 8
The channel is switched after the keys are released.
NOTE: An information display shows the active channel (see page 34).
ADVICE: The select keys are displayed in the right column of the
menu (see page 11).
Further information:
 Changing hotkeys or double hotkeys on page 40
 Changing select keys on page 42
 Defining select keys on page 29

Accessing computers by using a serial device

Another way to switch the channels is using a serial device that is connected to the
RS232 interface of the KVM switch.
A serial device can be a special keypad or a computer with an installed terminal
emulator.
The paragraph Switching to computers by using a serial device on page 19 provides more
information on this topic.
to select the computer you want to access and press
key combination at the console keyboard.
, the channel is not switched.
ESC
G&D DVIMUX8-OSD-PS/2 · 12
Getting started
Enter .
Ctrl and the
Select Computer
