Positioning the On-Screen Display

In the default configuration, the On-Screen Display of the KVM switch is displayed
in the middle of the console monitor. However, you can adjust the position to your
needs.
How to change the position of the On-Screen Display:
1. Press (standard) to open the On-Screen Display.
Ctrl+Num
2. Press to open the menu.
F1
3. Use the Arrow keys
4. Use the Arrow keys
5. Press the
Arrow keys
6. Press or the left mouse key.
Enter
7. Press F1 to save your settings.

Adjusting the scancode set of PS/2 keyboards

IMPORTANT: Only the Supervisor can change this setting.
If you press a key at the PS/2 keyboard, the keyboard processor sends a data packet
that is called scan code. The two common scancode sets (sets 2 and 3) contain differ-
ent scancodes.
In the default configuration, the user module interprets any entry made at the PS/2
keyboard with the scancode set 2.
Use the scancode set 3 if you cannot enter the pipe "|" or the arrow keys do not
work as expected.
to select Console Setup
to select Menu Position
MENU POSITION
Esc Enter
or use the mouse to move the menu to the desired position.
and press Enter .
and press Enter .
