19. How to Implement the Utility setting
to show Function menu, choose "Utility"
Click
Language
Choose the desired language.
Skin
Choose Black or Blue for interface skin. Then "Restart" button will appear. After clicking it, the
software will be closed and restarted to apply the new skin.
Open File
Choose BIN waveform file saved and open it, or just drag the file into the software interface to open it.
Print Preview
Click to open the Print Preview Window.
Instruction of the menu items in Print Preview Window:
File→ Page Set: Set the page margins
Print: Enter printing window
Exit: Close the Print Preview Window
View→ Page Transform: Switch the page orientation between landscape and portrait
Whole page: Display the full page on the screen
Face size: Display in actual size
Default Scale...: Display in a specified zoom factor
Show Wave Background: Check to display wave background color; uncheck to display
preview paper background
Set Preview Page Background: Click to display color picker dialog box to set the color of
preview page background
Save Image
Click to save screen shot as an image file in png, bmp or gif format.
Save/Refer
This function allows to store 8 reference waveforms. These waveforms can be displayed with the
current waveform simultaneously. The recalled waveform can´t be adjusted. The source can be CH1,
CH2 or Math.
To save the waveform of CH1 into object "a" and recall it, the steps are as follows:
1. Choose CH1 as source.
2. Choose "To Object" as "a".
3. Fillin "Object Rename", such as "sine". Click "OK". The object name is renamed as "a (sine)". This
step can be skipped.
4. Click "save".
5. Select "a (sine)" from the list, tick "Show", the reference waveform will appear on the screen. The
object name and relevant information will be displayed on the top left. You can continue to choose
another reference waveform to display. Click "Remove all" to clear all reference waveforms on the
screen.
If the chosen object has no stored waveform, it will display "No Saved" below.
-101-
