Removing the side
rack-holder frames
88
To re-fit the door, carry out the instructions given
above in the inverse direction. When the hinges B
are back in their seats, open the door all the way
and re-fit the safety catches of the hinges, lower-
ing the respective pins A (one for each hinge).
CAUTION: After re-fitting the door, always be sure
to re-fit the hinge safety catches.
The rack-holder frames can be removed to clean
them separately and to facilitate cleaning the oven
walls. The frames are hooked to the oven wall in
the three points indicated by the arrows in the fig-
ure (detail 1).
• Press downward with your fingers as shown in
detail 2 of the figure to release the frame from
the upper pin.
• Lift the frame upward and take it out.
To re-fit proceed in the inverse direction. Set the
lower part of the frame on the respective pins and
press the upper part against the oven wall until it
hooks onto the pin.
