Chapter 6 Technical data

This chapter summarises all the hardware characteristics of elmeg hybird 300systems and elmeg hybird 600
devices.

6.1 Scope of supply

Your device is supplied with the following parts:
elmeg hybird 300
elmeg hybird 600

6.2 General Product Features

The general product features cover performance features and the technical prerequisites for installation and opera-
tion of your device.
General Product Features elmeg hybird 300, elmeg hybird 600
Product name
Equipment dimensions without
cable (B x H x D):
Weight
LEDs
Power consumption of the
device
Voltage supply
hybird 300 / hybird 600
elmeg hybird 300
1x M 4 S/U+ 4U
1x MC CL
2x IP cable (3 m)
Data storage media (documentation, software, etc)
printed documentation
Fixing screws, dowels
Connection terminals
2x IP cable (3 m)
Network cable
2x Angle brackets
Data storage media (documentation, software, etc)
printed documentation
6x Knurled screws
elmeg hybird 300
(wall-mounted system)
500 mm x 370 mm x 75 mm
approx. 2.590 kg (incl. mains
unit without packing and cable)
4 (1x Power, 1x Status, 1x SD
Card, 1x Info)
Resting state (no module in-
stalled): ca. 12 watt
Activity for 3 modules FXS16
(50 % load, ca. 24 active calls):
ca. 50 W
1 Power supply
230 V ~
elmeg hybird 600 (rack-mounted system)
440 mm x 88 mm x 293 mm
approx. 5.2 kg (incl. mains unit without packing and cable)
6 (1x power, 1x status, 1x SD card, 3x functions only for module
replacement)
Resting state (no module installed): ca. 12 watt
Activity for 6 modules FXS16 (50 % load, ca. 48 active calls): ca.
80 W
2 Power supplies
230 V ~
