ANHANG D - PROTOKOLLFORMATE
Konfigurationsprotokoll (1)
HINWEIS: Die nachstehenden Werte sind nur als Beispiele gedacht. Für korrekte Werte und
Einstellungen drucken Sie ein Konfigurationsprotokoll des jeweiligen Analysators aus.
OPTI Medical OPTI CCA-TS
Nur für Forschungszwecke.
Nicht für den Gebrauch bei
diagnostischen Verfahren.
Configuration Report
DD-MMM-YY
HH:MM
S/N: XXXX
Version: ABCX.XX
Baro. Factor : 0.0 mmHg
Patient Info -
Pat.ID
: ON / Opt.
Oper.ID
: ON / Opt.
AccNum.
: ON / Opt.
DOB
: ON
Temp.
: ON
Sex
: ON
Hb Type
: ON
Sample Type: ON
tHb
: ON
MCHC
: ON
O2 Mode
: OFF
FIO2
: ON
RQ
: ON
P50
: ON
Vent Mode
: ON
TVol
: ON
MVol
: ON
PIP
: ON
Pplat
: ON
PS
: ON
PEEP
: ON
CPAP
: ON
Rate
: ON
Liter Flow : ON
I/E Ratio
: ON
BiLevel
: ON
User Def.
: ON
User Def.2 : ON
User Def.3 : ON
Puncture Site : ON
Bypass
: ON
Def. tHb
: 15.0 g/dL
Def. MCHC
: 33.3%
Def. FIO2
: 0.21
Def. RQ
: 0.84
Def. P50
: 26.7 mmHg
D-6
Reference Limits -
pH
7.200-7.600
PCO2 30.0- 50.0 mmHg
PO2
70.0-700.0 mmHg
Na+ 135.0-145.0 mmol/L
K+
3.50- 5.10 mmol/L
Cl-
95-115.0 mmol/L
Ca++ 1.12- 1.32 mmol/L
Glu
60.0-120.0 mg/dL
BUN
5.9- 19.9 mg/dL
Lac
0.90- 1.70 mmol/L
tHb
12.0- 17.0 g/dL
SO2
90.0-100.0 %
Controls Info -
Lev. 1 LimMin
LimMax
pH
7.120-7.240
PCO2
60.0- 76.0 mmHg
PO2
62.0- 86.0 mmHg
Na+
121.0-131.0 mmol/L
K+
2.60- 3.40 mmol/L
Cl-
84.0- 94.0 mmol/L
Ca++
1.44- 1.74 mmol/L
Glu
30.0-400.0 mg/dL
BUN
2.8-112.0 mg/dL
Lac
0.70- 1.10 mmol/L
tHb
18.2- 22.2 g/dL
SO2
76.0-82.0 %
QCLot: 9169 Exp: Mar2012
Lev. 2 LimMin
LimMax
pH
7.360-7.480
PCO2
37.0- 45.0 mmHg
PO2
90.0-114.0 mmHg
Na+
137.0-151.0 mmol/L
K+
4.40- 5.20 mmol/L
Cl-
102.0-112.0 mmol/L
Ca++
1.14- 1.34 mmol/L
Glu
30.0-400.0 mg/dL
BUN
2.8-112.0 mg/dL
Lac
1.90- 3.30 mmol/L
tHb
12.8- 15.8 g/dL
SO2
87.0- 93.0 %
QCLot: 9269 Exp: Mar2012
Lev. 3 LimMin
LimMax
pH
7.580-7.680
PCO2
17.0-27.0
mmHg
PO2
131.0-155.0 mmHg
Na+
151.0-165.0 mmol/L
K+
5.30- 6.30 mmol/L
Cl-
118.0-128.0 mmol/L
Ca++
0.66- 0.90 mmol/L
Glu
30.0-400.0 mg/dL
BUN
2.8-112.0 mg/dL
Lac
3.60- 5.40 mmol/L
tHb
8.1- 11.1 g/dL
SO2
94.0- 99.0
QCLot: 9369 Exp: Mar2012
Printouts -
Patient
: ON, copies 1
Calib.
: OFF
Ref. Rng : ON
Dest.
: Both
Connect. : Ethernet
IP Port
: 9100
IP Addr. : 192.168.13.211
Security -
Password : ENABLED
QC Lockout -
SRC Levels
QC Levels
New Lot
Miscellaneous
Units –
Units : Conventional
Temp
: Celcius
Time
: 24-hour
tHb
: g/dL
Ca++
: mmol/L
Glu
: mg/dL
BUN
: mg/dL
Lac
: mmol/L
Resolution : High
Correlation Factors -
Normal Cassettes
Slope
pH
1.000
PCO2
1.000
PO2
1.000
Na+
1.000
K+
1.000
Cl-
1.000
Ca++
1.000
Glu
1.000
BUN
1.000
Lac
1.000
tHb
1.000
SO2
1.000
Hardware -
Ext. Barcode
CF Delimiter
Gebrauchsanweisung – OPTI CCA-TS
%
: 0
: 0
: OFF
Offset
0.000
0.0
0.0
0.0
0.00
0.0
0.00
0.0
0.0
0.0
0.0
0.0
: OFF
:
