Operating instructions SATA anti-dust jet / SATA anti-dust jet X
insert with air piston [5-5] and screw in locking screw [1-6].
• Ensure correct position of locking screw [1-6]! Clos-
ing cap [1-5] could shoot out from the spray gun
body of the SATa anti-dust jet / X uncontrolled!

11. Trouble-shooting

• Please disconnect the SATA anti-dust jet / X from the compressed air
circuit prior to any cleaning and disconnect it from the supply voltage!
• Risk of electric shock!
Switch off the SATA anti-dust power pack and disconnect it
from the supply voltage for maintenance and repair work at
the electrode, the power pack and the rotating nozzle.
• Repair and maintenance work may be effected
by electrically skilled personnel only.
• These types of work may only be effected outside of the ex-area!
• Risk of combustion!
The solvent must have completely evapo-
rated prior to further operation.
Malfunction
SATA anti-dust jet / X
does not shut-off air
Result no longer ef-
fective
Warning!
Warning! Attention!
Cause
Clogged air piston seat
or worn air piston.
Insufficient com-
pressed air
The SATA anti-dust
power pack / X is out
of order or defective

Corrective Action

Clean air piston seat
and/or air piston,
exchange air piston
packing, chapter 10.1
Check the compressed
air system
Switch the power sup-
ply on; contact your
dealer, if necessary
EN
15
