Denon AVR-2803 Bedienungsanleitung Seite 25

[2] Listening over headphones
1
Plug the headphones' plug into
PHONES
the jack.
Connect the headphones to
the PHONES jack.
The pre-out output
(including the speaker
output) is automatically turned off when
headphones are connected.
[3] Turning the sound off temporarily (MUTING)
1
Use this to turn off the audio
output temporarily.
Press the MUTING button.
Cancelling MUTING
(Remote control unit)
mode.
Press the MUTING button again or adjust
the main volume level.
[4] Combining the currently playing sound with the desired image
1
Simulcast playback
Use this switch to monitor a video source other
than the audio source.
Press the VIDEO SELECT button, turn the
FUNCTION knob until the desired source
appears on the display.
FUNCTION
(Main unit)
Cancelling simulcast playback.
• Select "SOURCE" using the VIDEO
SELECT button and the FUNCTION knob.
• Switch the program source to the
component connected to the video input.
1
1
NOTE:
To prevent hearing loss, do not raise the volume level
excessively when using headphones.
1
1 1 1
Display
IN=V SOURCE
[5] Checking the currently playing program source, etc.
1
On screen display
• Each time an operation is
performed, a description of
that operation appears on
the display connected to the
(Remote control unit)
unit's VIDEO MONITOR OUT
jack.
Also, the unit's operating status can be
checked during playback by pressing the
remote control unit's ON SCREEN/DISPLAY
button.
Such information as the position of the input
selector and the surround parameter settings
is output in sequence.
Front panel display
• Descriptions of the unit's
operations are also displayed
on the front panel display.
In addition, the display can
(Main unit)
be switched to check the
unit's operating status while
playing a source by pressing
the STATUS button.
Multi-source recording/playback
[1] Playing one source while recording another (REC OUT mode)
1
Press the ZONE2/REC button.
(Main unit)
2
With "RECOUT SOURCE"
FUNCTION
displayed, turn the FUNCTION
knob to select the source you
wish to record.
• The "REC" indicator and the
(Main unit)
indicator of the selected
source light.
3
Set the recording mode.
• For operating instructions, refer to the manual
of the component on which you want to
record.
4
To cancel, turn the function
FUNCTION
knob and select "SOURCE".
• When "SOURCE" is selected,
the "REC" indicator turns off.
(Main unit)
ENGLISH
1
1
Using the dimmer function
• Use this to change the brightness of
the display.
The display brightness changes in
four steps (bright, medium, dim and
(Main unit)
off) by pressing the main unit's
DIMMER button repeatedly.
2,4 2
1
2
Display
REC PHONO CD TUNER DVD / VDP TV / DBS
VCR -1 -2 V.AUX / TAPE
RECOUT SOURCE
NOTES:
• Recording sources other than digital inputs
selected in the REC OUT mode are also output to
the Zone 2 preout jacks.
• Digital signals are not output from the REC
SOURCE or audio output jacks.
25
