9. Loading/saving temperature settings

You can save a preset temperature to each of the three control buttons (2), e.g. for different solder types or for SMD
soldering. By default, the control buttons (2) are programmed to the following temperature settings:
Button "1": 150 °C
Button "2": 270 °C
Button "3": 360 °C
You can overwrite these settings with your own temperature settings. The temperature settings are retained after the
soldering station is switched off.
If you enabled a preset temperature using one of the control buttons (2) and wish to manually change
the temperature, turn the temperature control dial (7) slightly in either direction. You can then change the
temperature using the temperature control dial (7).

a) Loading a temperature setting

Briefly press the control button for the temperature setting that you want to load. The new target temperature will be
displayed on the top line. If this is higher than the previous target temperature, the soldering tip will start to heat up (if
the temperature is lower, wait until the soldering tip has cooled down to the new temperature).

b) Saving a temperature setting

• Use the temperature control dial (7) to set the desired temperature (shown next to "SET" on the top line of the
display).
If the temperature control dial (7) is in the leftmost position and you wish to decrease the temperature, turn
the temperature control dial slightly in a clockwise direction. You can then set the temperature as usual.
If the temperature control dial (7) is in the rightmost position and you wish to increase the temperature,
turn the temperature control dial slightly in an anticlockwise direction. You can then set the temperature as
usual.
The temperature control dial (7) is not directly linked to the heating function (as on conventional analogue
soldering stations), because the temperature can also be selected using the control buttons.
• Hold down the control button that you want to assign a temperature to and wait until the set temperature flashes
three times and stays constant. This indicates that the temperature setting has been saved. Release the control
button.
The temperature will flash and "PS1", "PS2" or "PS3" will be displayed to the left of the temperature (de-
pending on which button you press). This indicates that the soldering station is saving the temperature
setting.
