Functional Test - Kessel Pumpfix F Comfort Einbau-, Wartungs- Und Bedienungsanleitung

No. Test
5.5
Key function OK
7 Measured values
CAUTION: Disconnect the unit from the mains during all servicing work! Heed safety
instructions!
7.1
Nominal current data in accordance with the type plate on the pump
8 Overall condition of the system
8.1 System tested and ready for operation
9 Maintenance
9.1 Maintenance and service work possible without limitations
9.2
Safety staff required in accordance with accident prevention regulations (inspection chamber entrance,
gas warning device)

Functional test

No. Test
1
Rinse the system with water
2 Function given, carry out function start
3 Infinitely with deeper installation
Is with closed cover plate without inflow connection and without Multistop
4 Cover removal, remove insert flap housing with flap
- Cover emergency closure to position CLOSED
- Tilt the motor swivel connection backwards
- Cover with pump connection can be lifted
- Open the locking lever of the cover, remove cover
- Pull the insert flap housing out with the flap and clean the parts, check sealing gaskets for cover and
insert flap housing
- Grease the guide parts for the insert flap housing and cover using fittings grease
- Insert the parts back into the drain body
5 Pressure pipe flap
- Clean the pressure pipe flap in the pump connection, test it and replace if necessary
- Unscrew seat for one-handed quick-action closure with flap, screwed with three Torx screws
(TX 25)
- Check the pressure pipe flap, clean and replace if necessary
6 Pumps
- Remove pump(s)
- Unscrew the intake cage/spiral housing
- Clean the ventilation bore
- Check the cutting blade for wear and replace if necessary
- Take the impeller off and clean it
- Install the parts again
- Insert the pump(s) again and fix in place
7 Functional test
- Submerse the pump probe in water (optical and acoustic warning equipment responds)
- Pump starts running
- Take the probe out of the water -> the pump switches off
Caution: Keep to the probe sequence!
Maintenance
