Reticle moving directions
A
Reticle's X and Y coordinates
B
USB connection indication
C
Contrast mode
D
SumLight™ mode
E
Brightness and contrast
F
adjustment
Clock
G
Low battery indicator
H
Clock setup
J
Indication for IR Illuminator power level
K
1.5x digital zoom
L
M Indication for external power supply
One shot zeroing
N
Limiting frame
O
Auxiliary cross
P
Indication of activation of wireless remote control
Q
R
PAL/NTSC video output signal selection
X=00 Y=00
A B C
x1.5
IR IR IR
J K
The Digisight is designed for observation and shooting in twilight or nighttime.
In complete darkness (no stars or the Moon) use of the built-in IR (or laser)
Illuminator is highly recommended. Your riflescope is a versatile device
designed for a wide range of professional and amateur applications such as
hunting, sports shooting, night video recording and observation.
6
O P
00 00 AM
D E F G
X
L M N Q
The riflescope has been designed for long-term usage. To ensure longevity
and performance, please adhere to the following:
Before use make sure that you have installed and fixed the mount
according to the instructions of the section "Installation of mount".
Store with the lens cap on in the carrying case.
Switch off the scope after use.
The riflescope cannot be submerged in water.
Attempts to disassemble or repair the scope will void the warranty!
Clean the scope's optical surfaces only if necessary, and use caution.
First, remove (by blowing with a blower brush or canned air) any dust or
sand particles. Then proceed to clean by using camera/lens cleaning
equipment approved for use with multicoated lenses. Do not pour the
solution directly onto the lens!
The riflescope can be used in operating temperatures ranging from
-20 °C... +50 °C. However, if it has been brought indoors from cold
temperatures, do not turn it on for 3 to 4 hours. This will prevent external
optical surfaces from fogging.
If the scope is unable to mount onto the rifle securely, or you have doubts
about the mounting system, see a qualified gunsmith. Using the weapon
with a poorly mounted scope can lead to inaccurate target shooting!
To ensure reliable performance, it is recommended to carry out regular
technical inspections of the unit.
Do not leave batteries in the unit if it is not going to be used for an extended
period (1 month or more)
Batteries shall not be exposed to excessive heat such as sunshine, fire or
the like.
H
Unscrew and remove the battery cover
R
(22).
Install four AA batteries according to the
marking on the battery compartment
cap.
Replace and screw back the battery
cover tightly.
