Pulsar Digisight Anleitung Seite 3

ENGLISH
Optical characteristics
Generation
Magnification, x
Magnification with digital zoom (1.5x), x
Objective lens
Field of view, degree / m (at 100m)
Field of view with 1.5x digital zoom,
degree / m (at 100m distance)
Eye relief, mm
Exit pupil, mm
Resolution, lines/mm
Max. detection range built-in illuminator on, m/yds*
Eyepiece dioptre adjustment, D
Close-up distance, m/yds
Click value, mm at 100 m (H/V)
Click range, clicks (H/V)
CCD array characteristics
Output video signal standard
Type of CCD array
Resolution, pixel
Format (physical dimensions)
Display characteristics
Type
Resolution, pixel
Diagonal, inch
Built-in Laser IR Illuminator
Wavelength, nm
Equivalent power (changing range), mW
Safety class for laser equipment
according to IEC 60825-1:2007
Output power for laser radiation, not more than
Operational characteristics
Operating voltage, V
External power supply / consumption power
Degree of protection, IP code (IEC 60529)
Operating temperature
Operation time with one set of rechargeable
batteries (built-in IR off/on), hour
Operation time with external power supply
EPS3/EPS5, hour
Operating frequency of wireless RC
Operating voltage, V / Battery of RC
RC battery life
Max. shock resistance
Dimensions, mm
Approx. weight, kg
* Max. detection range of an object measuring 1.7x0.5 m in natural night conditions
(0.05 lux, quarter moon).
2
Digital Digital
4.5 4.5
6.8 6.8
50 mm ƒ1.0
5/8.7 5/8.7
3.25/5.7 3.25/5.7
67 67
6 6
≥ 55 ≥ 55
600/656 450/492
±4 ±4
5.5 5.5
13/13 13/13
80/100 80/100
CCIR CCIR
ICX255 ICX255
500 (H) х 582(V)
1/3" (4.8x3.6mm)
OLED OLED
640х480 640х480
0.31 0.31
780 915
150 (90-110-150)
1 1
13 mW 20 mW
6 (4xAA) 6 (4xAA)
DC 8.4-15V / 3W
IP44 IP44
-20 °C... +50 °C / -4 °F... +122 °F
4 / 3.5 4 / 3.5
9 / 20 9 / 20
2.4 GHz 2.4 GHz
3 / CR2032
Two years
6000 Joules
340x95x94
1 1
Riflescope Digisight
Remote control
Carrying case
Mount**
User manual
Cleaning cloth
Warranty card
** Mount may not be included for certain orders.
For improvement purposes, design of this product is subject to change.
Optics:
Fast Aperture Lens 50 mm ƒ1.0
Long Eye Relief (67 mm)
Accurate Internal Focus Adjustment
Optical magnification 4.5x
Electronics:
Quality OLED (640x480 Pixel)
Digital zoom 1.5x
Highly Sensitivity CCD Array
Signal Processing Program Sum Light™
Reticle dot colour inversion
One Shot Zeroing
Resistant to Bright Light Exposure
Extra features:
Built-in laser IR Illuminator with adjustable power
Wireless remote control
Wide range of image brightness and contrast adjustment
Low battery indicator
Interchangeable mounts
Alternative reticle upload
Ip44 degree of protection
Built-in clock
External power supply
Video output enabling video recording/image capture
3
