5. MENU SCREEN SETUPS

DATA I/O SCREEN

Item
CAM SWITCH Set according to the tape of time-lapse VCR connected.
• Not displayed dur- OFF : The CAM SW input signal from the time-lapse VCR is
ing the B mode
operation. LOW : The camera video is switched at the negative going (L)
HIGH : The camera video is switched at the positive going (H)
I/O Set according to the input/output signals received through the
rear panel DATA I/O terminals.
16ALM IN
8ALM OUT/8 ALM IN : Sets terminals 1 to 8 as the alarm output
8SEL OUT/8 ALM IN : Sets terminals 1 to 8 as the selection out-
8SEL OUT/8 ALM OUT: Sets terminals 1 to 8 as the selection out-
16SEL OUT
16ALM OUT
NOTE
• When changing the set value, be sure to turn the power
from OFF → ON in order to register the reset values.
INPUT Set the assignment of the DATA I/O to be used as the input
ASSIGNMENT mode.
REF. : Page 31.
NOTE:
When the I/O item above is selected to any of the following
items, the INPUT ASSIGNMENT screen will not appear.
• 8 SEL OUT/8 ALM OUT
• 16 SEL
• 16 ALM OUT
E-30
Function
not accepted.
of the CAM SW signal.
Set to "LOW" when using a JVC time-lapse VCR.
of the CAM SW signal.
: Sets all of the 16 channels as alarm input
terminals.
terminals and terminals 9 to 16 as the alarm
input terminals.
put terminals and terminals 9 to 16 as the
alarm input terminals.
put terminals and terminals 9 to 16 as the
alarm output terminals.
: Sets all of terminals 1 to 16 as the selec-
tion output terminals.
: Sets all of terminals 1 to 16 as the alarm
output terminals.
Options Default
OFF, LOW
LOW,
HIGH
16 ALM IN, 16ALM IN
8 ALM OUT
/ 8 ALM IN,
8 SEL OUT/ 8 ALM
IN,
8 SEL OUT/ 8 ALM
OUT,
16 SEL OUT,
16 ALM OUT
DATA I/O
CAM SWITCH LOW
I/O 16ALM IN
INPUT ASSIGNMENT..
INPUT ASSIGNMENT
TERMINAL 1
CAMERA IGNORE
POSITION HOME
ALARM TEXT NONE
POLARITY MAKE
