1. GENERAL INFORMATION
This product complies with the requirements of the following European Community Directives:
2004/108/EC (Electromagnetic Compatibility) and 2006/95/EC (Low Voltage) as amended by
2004/22/EC (CE-Marking). Overvoltage category II; pollution degree 2.
1.1. Introduction
®
1100 is a high accuracy micro-processor controlled RF Signal generator covering
PeakTech
frequency range of 100kHz ~ 150MHz.
In addition to an excellent AM/FM modulation capability, the output level can vary from -20dBµ to
126dBµ in 0.1dB step.
This signal generator is designed specifically to test AM/FM radio, CB, and cordless phones under
product development and production environment.
1.1.1. Carrier Frequency
The operating frequency range of PeakTech
digit LED displays the frequency.
The desired carrier frequency is entered directly by key pad or rotary knob. The frequency can also
be stepped.
Besides, the delta F capability is very convenient for setting frequency offset from a reference
frequency.
1.1.2. RF Output
Level can vary from -20dBµ to 126dBµ in 10dB, 1dB and 0.1dB steps using key pad or rotary knob.
Also an output level value can be entered directly from key pad or stepped in desired increment or
decrement using step keys.
Independent A, B, C, and D level memory keys can store 4 most often used levels.
1.1.3. Modulation
AM and FM can be generated either by internal 400Hz/1kHz oscillator or by external modulation
signals.
Using
(SHIFT) key, single key stroke can set AM 30%, FM 3.5kHz / 22.5kHz / 75kHz, and stereo
100% / 30%.
1.1.4. Memory Function ( Store/Recall )
Up to 100 different combinations of frequency (F), output level (L), and modulation (M) can be stored
and recalled. By defining BEGIN and END addresses, the stored settings in between can be
sequenced for repeated measurements. There are also 4 additional memories to store the output
levels which can be recalled by single key stroke.
®
1100 is 100kHz to 150MHz with PLL accuracy. The 7
-35-
