11. Memory Setting / Sequential Recall
Pressing this key turns on the key-top LED showing that the key is activated. Only then, the
data (Frequency-Level-Modulation) stored in the memory can be recalled.
When key-top LED is OFF, an address must be established before recalling the data store in
that address.
STO (Store)
Used to store current state (Frequency-Level-Modulation) into an address.
Set an address and the data (Frequency-Level-Modulation), then press the key followed by
key.
RTN (return)/BEGIN
Returns to BEGIN address during address rotation operation.
BEGIN address is entered by pressing and 'RTN (BEGIN)' keys in sequence after an address
is established.
RCL (Recall)/END
Data stored in the current address is recalled.
To enter END address for address rotation operation, press and 'RCL(END)' keys in sequence
after an address is established.
12. Address Up/Down key
Increase or decrease the address by unit of 10 or 1.
13. Modulation Setting key
EXT key (
1kHz key (
400Hz key (
Stereo Key (
Main Key (
Left Key (
Right Key (
SUB Key (
nd
Shift key (2
( (SHIFT)
FM key (
AM key (
Pilot ON/OFF (
14. Setting Menu (frequency, Level, level ,Modulation )
FREQ key
Allows direct entry of frequencies from the key pad. When pressed, Frequency display
becomes blank and
key. To cancel during the operation before
LEVEL key
Allows direct entry of output level from the key pad.
ADDR (ADRS) key
) : Turn ON/OFF external modulation input.
) : Select the internal 1kHz.
) : Select the internal 400Hz.
) : Turn ON/OFF Stereo mode during FM Stereo.
) : Activate MAIN modulation during FM Stereo.
) : Activate LEFT modulation during FM Stereo.
) : Activate RIGHT modulation during FM Stereo.
) : Activate SUB modulation during FM Stereo.
function Key)
: let you do blue letters function.
) : Turn on /off FM.
) : Turn on /off AM.
) : Turns ON/OFF the pilot tone during FM Stereo.
LED is blinking. Then enter the frequency value followed by
key, depress
-41-
key again.
