PeakTech 1100 Bedienungsanleitung Seite 54

Table 3-1 DEFAULT SETTING
----------------------------------------------
MOD
FREQ
LEVEL
ADDRESS
FREQ STEP
LEVEL STEP
CURSOR POSITION
GPIB ADDRESS
BEGIN ADDRESS
END ADDRESS
LEVEL A
LEVEL B
LEVEL C
LEVEL D
SEQ
----------------------------------------------
3.3.6.3. Program Version Number (
FREQUENCY DISPLAY : "VEr-1.0" ( The Latest version is displayed )
3.3.6.4. Range Logic Toggle (
1) Press ,
2) then, displays the current logic state on ' Frequency Display ' window.
35...1
35...1
35...0
35...0
3. This Function is toggle function,
So, when press above keys then the 'Range Output' is reversed
3.3.6.5. FM Calibration Mode (
1) This function is to Enter 'FM calibration Mode'.
2) Press ,
Caution
A. It means Protect to user (so, please users do not this function).
: OFF
: 100MHz
: 126dBu
: 00
: 10MHz
: 10dB
: FREQ 1kHz
: 02
: 00
: 99
: 100dBu
: 100dBu
: 100dBu
: 100dBu
: ON
, )
key, then change ' Range output ' for Dummy Control at Rear Panel.
the 'Range logic output' is +5V for ( ≥35 MHz ).
the 'Range logic output' is +0V for ( < 35 MHz ).
the 'Range logic output' is +0V for ( ≥ 35 MHz ).
the 'Range logic output' is +5V for ( < 35 MHz ).
,
, then , 'JPr oPn' appears on display window.
, )
)
-53-
