3.3.4.2. Direct Numeric Entry Mode
1) Press Key.
ADDRESS DISPLAY goes blank and
ADDRESS returns to its original state if no further input is entered during 15 LED blinks.
2) Enter data with numeric keys.
Correct with
3) Complete with
ADDRESS DISPLAY blinks once indicating the value is stored in the memory. In case the
instrument is in 'Sequential Recall Mode', the stored data at the address will appear
immediately (refer to 3.3.5 5).
4) Single digit addresses (0 to 9) can be entered directly from numeric keys if a numeric value is
entered without first selecting ADDR key.
☞ ☞ ☞ ☞
To Cancel the Procedure , Press
3.3.4.3. Address Rotation Function
In case a certain sequence of the instrument settings must be repeated, 'Address rotation function' is
helpful. In this mode, a sequence of addresses with data is rotated upon completing 'END Address',
the control returns to 'BEGIN Address' automatically.
1) To Store 'Begin Address'
2) To Store 'End Address'
Example 1)
Instrument setting data is stored in address 1 to 15 and to be repeated from 1 to 15
1) Set desired data (Frequency, Level, Modulation ...) into memory address 1 to 15.
2) Set 'Address' to 1 (Press
3) Set 'Begin Address' = 1. (Press
4) Set 'Address' to 15. (Press
5) Set 'End Address' = 15. (Press
☞ ☞ ☞ ☞
A. IF it is desired to return to 'Begin address' before finishing 'End address' while performing
'Address Rotation function', Press
☞ ☞ ☞ ☞
B. To go outside of 'Begin Address' and 'End address', use direct numeric entry mode to set
new memory address.
☞ ☞ ☞ ☞
C. Address Rotation Function can be cancelled by setting Address
Begin Address
End Address
D. Then, all 100 addresses can be accessed and sequenced.
key if necessary.
Key.
Press
Press
key)
(SHIFT),
,
(SHIFT),
= 00
= 99
Key LED starts blinking.
key before key
(SHIFT),
(SHIFT) ,
).
, , key )
).
key.
