Concept2 PM3 Handbuch Seite 6

Notes:
1) remove batteries or battery pack from the pm3 or pm4
if monitor will not be used for a period of four months or
more .
Safety Information for PM4 Rechargeable Battery Pack
Do not:
• Open the plastic case
• Drop the battery pack
• Allow battery pack pins to touch each
other or any metal object
• Use if damaged or leaking
• Trash, incinerate, crush, etc.
WARNING: If batteries leak, do not use them. Battery fluids are corrosive and can damage eyes, irritate skin, etc.
if contact occurs, wash affected area immediately and thoroughly with water .
MISCELLANEOUS
Cleaning the PM
use a cloth lightly dampened with water only . do not spray with a cleaner or leave in the rain .
Formulas Used
Watts = 2.80/(sec/meter)^3
Calories/Hour = Kcal/hr = (watts) x (4) x (0.8604) + 300
Bottom View of PM
port for the optional USB port for connecting to a computer . Beveled
polar™ heart rate
corners on USB cable plug face the back of the
receiver .
monitor . do not force when plugging in .
See concept2.com/pm for current information .
TROUBLESHOOTING
1 . if the pm malfunctions or does not "wake up," reset pm:
• Insert a pen/pencil tip into the reset hole on the back and press lightly.
• Remove the batteries for 30 minutes and insert two new alkaline D-Cell (LR20) batteries.
to change language: press MENU/BACK until screen stops changing . press fifth grey button on right, then press second grey
2 .
button on right twice, and select your language . alternately, hold down CHANGE UNITS and CHANGE DISPLAY and reset
monitor . You can then select your desired language . (Note: this procedure will reset pm to factory settings .)
3. If your computer does not recognize that your PM3/PM4 is connected to it try one of the following:
• Use another computer and/or USB cable.
• Remove batteries and USB cable for 30 minutes then reinsert batteries and try again.
Refer to concept2.com/pm for more information and software updates.
Battery compartment: Loosen screw and press
thumbstrike in direction shown to open .
Do:
• Use only in a PM4; if not used in PM4, store carefully so pins are not shorted
• Keep clean and dry
• Use between 0˚ and 40˚ C
• Charge (row or ski, or plug PM4 into USB) after prolonged period of non-use
• Keep battery pack away from children
• Recycle properly
flywheel sensor cable must be connected
here for the pm to operate .
Back View of PM
PM4
6
PM3
PM4
PM3
race system jacks
Battery cover
reset here
