Installing or replacing the switch card

IMPORTANT: Installing and replacing the switch card requires using a certain force.
Make sure to put force on both levers.
How to replace the switch card:
1. Turn off the power supply modules at the
2. Press the card's red sliders in the direction of the arrow to release the lever.
3. Press the levers in the direction of the card's left and right outer edges.
4. Pull the card horizontally out of the housing.
How to install the switch card:
1. Press both red sliders of the card you want to install in the direction of the arrow
to release the lever.
2. Place the card on the slot's guard rail.
3. Press the middle of the front panel to slide the card horizontally in the slot.
4. Make sure that the levers are connected to the housing and are placed at the
height of the holes of the perforated rail.
5. Push the levers inwards without using much force and fix the card in the housing.
Modular design of the matrix switch
Power 1 , Power 2 and Power 3
G&D ControlCenter-Digital-80 · 9
buttons.
