Modular design of the matrix switch

Installing or replacing power supply modules

Power supply modules can be installed (hot plug) or replaced (hot swap) during
operation.
NOTE:
You can replace a power supply module during operation if another power
supply module continues to supply power to the matrix switch.
How to replace a power supply module:
1. Pull the locking lever up and hold it in this position.
2. Fold down the handles of the power supply module.
3. Pull the module out of the housing.
IMPORTANT:
The power supply module has a high operational temperature.
Beware of burnings!
How to install a power supply module:
1. Slide the module into the slot.
2. Once the locking lever clicks, the module is completely inserted.

Installing or replacing the controller card

How to replace the controller card:
1. Turn off the power supply modules at the
2. Press the card's red sliders in the direction of the arrow to release the lever.
3. Press the levers in the direction of the card's left and right outer edges.
4. Pull the card slightly upwards to remove it from the housing.
How to install the controller card:
1. Turn off the power supply modules at the
2. Press the red sliders of the card you want to install in the direction of the arrow to
release the lever.
3. Place the card on the slot's guard rail.
4. Press the middle of the front panel to slide the card horizontally in the slot until
the levers are connected to the housing.
5. Push the levers inwards without using much force and fix the card in the housing.
8 · G&D ControlCenter-Digital-80
Power 1 , Power 2 and
, and
Power 1 Power 2
Power 3 buttons.
buttons.
Power 3
