Other Notes On Operation; Technical Specifications - HomeMatic HM-LC-Dim1PWM-CV Installations- Und Bedienungsanleitung

13 Other notes on operation

If the device reaches a too high temperature during
operation (due to insufficient air circulation, for
example), the load will first of all be reduced by
lowering the brightness. If the overtemperature
persists, the load will be disconnected. If the actuator
is operating via the Homematic central control unit
(CCU), please note that the central control unit will not
be informed in the event of a load failure.

14 Technical specifications

Device short description:
Supply voltage:
Max. switching capacity:
Current consumption:
52
HM-LC-Dim1PWM-CV
12 V - 24 V
DC
60 W (5 A@12 V;
2.5 A@24 V)
5 A max.
DC
