Make sure that the cables to the LED stripes
are dimensioned sufficiently for the voltage
supply and the number of LED stripes as well
as the overall cable lengths to assure that all
stripes will receive the full operating voltage
and that overheating of cables is avoided.
• Close the housing of the dimmer by placing and
screwing the cable plate. Thereby, please take care
that cables are covered and fixed by the cable clamb
which serves as strain relief.
• The dimmer is mounted by the fastening tabs which
have to be screwed tightly to the background. The
connection cables have to be fixed while being laid
(e.g. by nail or cable clamps, tubes or cable ducts).
• -If the power supply has to be connected to the
power network, plug the power supply into a socket.
• If a permanent connection to the power network is
provided (e.g. by a junction box), please disconnect
the electric circuit from the power network (see sec.
2 Hazard Information).
• Please do now connect the power supply to the
power network.
• Switch the power back only if all cables and
distributors are fixed and the junction boxes are
closed.
