6.2.1 Teaching-in to Homematic devices

If you would like to teach-in the dimming acutator to
one or more Homematic devices, you must put the
devices to be taught-in into teach-in mode and select
the required teach-in channel. To do this, proceed as
follows:
During teach-in, please make sure you maintain
a distance of at least 50 cm between the
devices.
• Activate the teach-in mode of your dimming actuator.
Therefore, press and hold down the channel button
for at least 4 seconds. The device LED will flash
continuously to indicate that teach-in mode is active.
The teach-in time is 20 seconds.
• Now put the device you wish to teach-in the
dimming actuator into teach-in mode. Please follow
the relevant operating manual instructions of the
corresponding device.
If no teach-in is carried out, teach-in mode will be
exited automatically after 20 seconds. If other
devices are also in teach-in mode, they will be
taught-in.
