Rigid cable
[mm
]
2
1.00 – 2.50
6.1 Mounting site
To guarantee sufficient air circulation, the mounting
site has to be dry, dust-free and sufficiently ventilated.
Also heat load e.g. by direct sun, heating pipes
etc. has to be avoided. If sufficient air circulation is
guaranteed, mounting into furniture or wooden ceilings
is possible (see „Technical data" for mounting label).
6.2 Mounting
• Remove the cable plate from the dimmer by
loosening the fastening screw.
• Strip 8 mm of insulation from the ends of the mains
wires between the dimmer and power supply as well
as the LEDs.
• Connect the dimmer with the power supply unit and
the LEDs according to the diagram on page 33.
• Make sure that all connections are tightly and safely
screwed on so that there can be no short circuit
between the two wires.
42
Flexible cable
without end
sleeve [mm
1.00 - 2.50
Flexible cable
with end sleeve
]
[mm
2
1.00 – 2.50
]
2
