Using A Coin Unit To Start; Ending A Massage - Wellsystem RELAX_PLUS Original-Gebrauchsanweisung

08/2016 1009864-02A
NOTE:
Any massage time setting can be entered prior to starting
when using a chip card (up to the maximum default time
permitted). The massaging pressure can be decreased or
increased at any time whilst the unit is working.
The type of massage cannot be changed!
– Setting the massage time – see page 34.
– Insert the chip card.
– Lie down on the unit. In doing so place your head on the positioned head-
rest.
– Press the START / STOP button.
The program stored on the chip card will run automatically.
Chip card inserted incorrectly
If the chip card is inserted incorrectly, the error message Err is shown on the
display.
3.3.2

Using a coin unit to start

– Set the massage time on the coin device.
– Lie down on the unit. In doing so place your head on the positioned head-
rest.
– Select the type of massage that you want or insert the chip card.
– Press the START / STOP button.
3.4

Ending a massage

The massage will be terminated automatically after the set massage time has
expired. A flashing StOP sign will be shown in the display.
When the set massage time has expired, the nozzles move at high speed to
the head end and then change to a smoothing, final massage. The pressure
is reduced for the final massage. This pressure can only be changed by cus-
tomer service. The nozzles move once completely from the head end to the
feet end as for a full body massage.
The massage does not end until the nozzles stop at the end of the foot
and the display blinks at 0.00.
The final massage is omitted if a chip card is not being used. At the end of the
massage time, the nozzle carriage moves to the head end and comes to a
stop there.
Operation
Operating instructions – 29/46
