Technische Daten - Bender ISOMETER isoGEN423 Kurzanleitung

Technische Daten

( )* = Werkseinstellung
Isolationskoordination nach IEC 60664-1/IEC 60664-3
Definitionen:
Messkreis (IC1).......................................................................................................................................L1/+, L2/-
Versorgungskreis (IC2).................................................................................................................................. A1, A2
Ausgangskreis (IC3) .................................................................................................................................11, 14, 24
Steuerkreis (IC4)............................................................................................................................... E, KE, T/R, A, B
Bemessungsspannung............................................................................................................................................400 V
Überspannungskategorie............................................................................................................................................. III
Bemessungs-Stoßspannung:
IC1/(IC2-4).................................................................................................................................................................6 kV
IC2/(IC3-4).................................................................................................................................................................4 kV
IC3/IC4 ......................................................................................................................................................................4 kV
Bemessungs-Isolationsspannung:
IC1/(IC2-4)...............................................................................................................................................................400 V
IC2/(IC3-4 )..............................................................................................................................................................250 V
IC3/IC4 ....................................................................................................................................................................250 V
Verschmutzungsgrad ................................................................................................................................................... 3
Sichere Trennung (verstärkte Isolierung) zwischen:
IC1/(IC2-4) ...................................................................................................... Überspannungskategorie III, 600 V
IC2/( IC3-4 ) .................................................................................................... Überspannungskategorie III, 300 V
IC 3/IC4............................................................................................................ Überspannungskategorie III, 300 V
Spannungsprüfungen (Stuckprüfung) nach IEC 61010-1:
IC2/( IC3-4 ) ............................................................................................................................................. AC 2,2 kV
IC 3/IC4 .................................................................................................................................................... AC 2,2 kV
Versorgungsspannung
Versorgungsspannung U
Toleranz von U
....................................................................................................................................... -30...+15 %
s
Frequenzbereich U
..................................................................................................................................... 47...63 Hz
s
Eigenverbrauch .......................................................................................................................................≤ 3 W, ≤ 9 VA
isoGEN423_D00221_01_Q_DEEN/03.2018
......................................................................................... AC 100...240 V/DC 24...240 V
s
