ISOMETER® isoGEN423
Insulation monitoring device for unearthed
AC, AC/DC and DC systems (IT systems) up to
3(N)AC, AC 400 V, DC 400 V. Software version: D0494
This operating manual is designed for electrically skilled persons working in
electrical engineering and electronics! It does not replace the operating ma-
nual. Ensure that personnel has read this manual and understood all instruc-
tions relating to safety. The manual can be found at:
https://www.bender.de/en/service-support/downloads

1. Intended use

The ISOMETER® monitors the insulation resistance of unearthed AC,
AC/DC and DC systems (IT systems) with nominal system voltages from
3(N)AC, AC/DC 0...400 V or DC 0...400 V. The maximum permissible system
leakage capacitance C
influence the operating characteristics, when a minimum load current of DC
10 mA flows. A separate supply voltage allows de-energised systems to be
also monitored. In order to meet the requirements of applicable standards,
customised parameter settings must be made on the equipment in order to
adapt it to local equipment and operating conditions. Please heed the limits
of the area of application indicated in the technical specifications.
Any use other than that described in this quickstart is regarded as improper.
14
is 5 μF. DC components existing in AC systems do not
e
To ensure that the ISOMETER® functions correctly, a mains
internal resistance of
L2/- via the source (e.g. the transformer) or the load.
≤
1 kΩ must exist between L1/+ and
