Note:
The operating manual is part of this product.
It includes important instructions for the safe, proper and
economic operation of the product, for avoiding danger,
for minimising repair costs and downtimes and for in-
creasing the reliability and extending the service life of the
product. In addition to the safety instructions in this oper-
ating manual, you must also observe the regulations ap-
plicable to the operation of the product in your country.
Familiarise yourself with all operating and safety instruc-
tions before using the product. Only operate the product
as described and for the specified areas of application.
Keep the operating manual in a good place and hand
over all documents when passing the product on to third
parties.
2 Product description (Fig. 1-10)
1. On/off switch
2. Handle
2a. Fixing screw
3. Carrying strap
3a. Buckles
4. Engine unit
5. Spark plug connector
5a. Spark plug
6. Choke lever
7. Pull starter
8. Fuel filler cap
9. Fuel tank
10. Air filter cover
10a. Locking mechanism
10b. Air filter
11. Throttle
11a. Locking lever
12. Flexible tube
12a. Guide bar
12b. Hose clamp (large)
12c. Hose clamp (small)
13. Top tube
14. Bottom tube
14a. Fillister head screw
15. Nozzle
15a. Fillister head screw
16. Oil-petrol mixing bottle
17. Installation spanner
18. Open-ended spanner, AF 8/10 mm
19. Allen key, 4 mm
20. Allen key, 5 mm
21. Cable ties
22. Primer
23. Adjusting screw (idling)
3 Scope of delivery (Fig. 1, 2)
Item QuantityDesignation
4. 1 x Engine unit
12. 1 x Flexible tube
12b. 1 x Hose clamp (large)
12c. 1 x Hose clamp (small)
13. 1 x Top tube
14. 2 x Bottom tube
14a. 2 x Fillister head screw
15. 1 x Nozzle
15a. 1 x Fillister head screw
16. 1 x Oil-petrol mixing bottle
17. 1 x Installation spanner
24 | GB
18. 1 x
19. 1 x
20. 1 x
21. 3 x
1 x
1 x
4 Proper use
Only use the cordless leaf blower for the following purpos-
es:
• For collecting leaves or general garden waste such as
prunings or for removing them from hard-to-reach
places.
The product may only be used in the intended manner.
Any use beyond this is improper. The user, not the manu-
facturer, is responsible for damages or injuries of any type
resulting from this.
An element of the intended use is also the observance of
the safety instructions, as well as the assembly instruc-
tions and operating information in the operating manual.
Persons who operate and maintain the product must be
familiar with the manual and must be informed about po-
tential dangers.
The liability of the manufacturer and resulting damages
are excluded in the event of modifications of the product.
The product may only be operated with original parts and
original accessories from the manufacturer.
The safety, operating and maintenance specifications of
the manufacturer, as well as the dimensions specified in
the technical data, must be observed.
Please note that our products were not designed with the
intention of use for commercial or industrial purposes. We
assume no guarantee if the product is used in commercial
or industrial applications, or for equivalent work.
Explanation of the signal words in
the operating manual
DANGER
Signal word to indicate an imminently haz-
ardous situation which, if not avoided, will re-
sult in death or serious injury.
WARNING
Signal word to indicate a potentially hazard-
ous situation which, if not avoided, could re-
sult in death or serious injury.
CAUTION
Signal word to indicate a potentially hazard-
ous situation which, if not avoided, could re-
sult in minor or moderate injury.
ATTENTION
Signal word to indicate a potentially hazard-
ous situation which, if not avoided, could re-
sult in product or property damage.
www.scheppach.com
Open-ended spanner, AF 8/10 mm
Allen key, 4 mm
Allen key, 5 mm
Cable ties
Backpack leafblower
Operating manual
