Scheppach LB5200BP Originalbetriebsanleitung Seite 23

Table of contents
1 Introduction ........................................................
2 Product description (Fig. 1-10)...........................
3 Scope of delivery (Fig. 1, 2) ...............................
4 Proper use..........................................................
5 Safety instructions..............................................
6 Unpacking ..........................................................
7 Technical data....................................................
8 Assembly............................................................
9 Before commissioning........................................
10 Operation ...........................................................
11 Working instructions...........................................
12 Cleaning and maintenance ................................
13 Transport............................................................
14 Storage...............................................................
15 Repair and ordering spare parts ........................
16 Disposal and recycling .......................................
17 Troubleshooting .................................................
18 EU Declaration of Conformity.............................
19 Exploded view .................................................... 347
Explanation of the symbols on the
product
Symbols are used in this manual to draw your attention to
potential hazards. The safety symbols and the accompa-
nying explanations must be fully understood. The warn-
ings themselves will not rectify a hazard and cannot re-
place proper accident prevention measures.
Attention! Failure to observe the safety signs
and warning information affixed to the prod-
uct and failure to observe the safety and op-
erating manual can result in serious injury or
even death.
Before commissioning, read and observe
the operating manual and safety instruc-
tions!
Wear safety goggles.
Wear hearing protection. Excessive noise
can result in a loss of hearing.
Wear protective gloves.
Wear sturdy footwear!
Danger due to parts flying off while the en-
gine is running.
23
24
24
24
25
28
28
28
29
30
32
32
33
33
33
34
34
35
+
114
1 Introduction
Manufacturer:
Scheppach GmbH
Günzburger Straße 69
D-89335 Ichenhausen
Dear Customer
We hope your new product brings you much enjoyment
and success.
Note:
In accordance with the applicable product liability laws, the
manufacturer of this product assumes no liability for dam-
age to the product or caused by the product arising from:
• Improper handling
• Non-compliance with the operating manual
• Repairs carried out by third parties, unauthorised spe-
cialists
• Installing and replacing non-original spare parts
• Improper use
www.scheppach.com
Make sure that other persons maintain a
sufficient safety distance.
Danger of injury due to rotating blade! Keep
hands and feet outside the openings when
the product is running.
Danger of injury! Never have your hands
near the blades.
The motor becomes very hot during opera-
tion, do not touch!
Press the "Primer" fuel pump 7x.
Tank contents
Mixing ratio of fuel to 2-stroke engine oil
40:1
Naked flames or smoking near the device is
strictly prohibited!
Guaranteed sound power level of the product.
The product complies with the applicable
European directives.
The product complies with the applicable
Serbian directives.
GB | 23
