2. Fold the spacer (16) up (resting position)
when it is not needed.
Extending the cutting line
The tool is equipped with a fully automatic
line tracker. The line extends automatically
every time the tool is switched on. For prop-
er functioning of the automatic line exten-
sion mechanism, the spool (15) must have
stopped completely before you restart the
tool. If the lines are initially longer than the
cutting circle, the line cutter (35) will auto-
matically shorten it to the correct length.
Procedure (Fig. G)
1. Check the nylon lines regularly for dam-
age and make sure the cutting line still
has the length specified by the line cutter.
2. If no line ends are visible:
Replace the spool (see Maintenance,
p. 35).
3. Adjust the line length manually:
Remove the battery (20) from the tool.
Lightly pull on the line end and press the
locking button (34) repeatedly if neces-
sary until the line end protrudes beyond
the line cutter (35).

Checking the battery charge level

LEDs
red, orange, green
red, orange
red
1. Press the button (22) next to the charge
level indicator button (23) on the battery
(20).
The LEDs of the charge level indicator
show how much charge remains in the
battery.
2. Charge the battery (20) when only the red
LED on the charge level indicator (23) is
illuminated.

Charging the battery

See also the charger instruction manual.
Notes
• If warm, allow the battery to cool before
charging.
• Do not expose the battery to direct sun-
light or temperatures ≤ 50 °C for long
periods of time. In particular, avoid pla-
Meaning
Battery charged
Battery partially
charged
Battery needs to be
charged
GB
cing the product on radiators or storing it
in vehicles parked in the sun.
Procedure
1. If necessary, remove the battery (20) from
the cordless tool.
2. Slide the battery into the charging slot of
the charger (24).
3. Plug the charger into an outlet.
4. Once charging is complete, disconnect
the charger from the mains supply.
5. Pull the battery charging slot out.
Control LEDs on the charger (24)
green red
lights up —
— lights up
— flashes
flashes flashes

Operation

Working with the device

WARNING! Risk of injury! Pay attention to
the following instructions.
• Do not cut damp or wet grass.
• Before starting the device, make sure
that the cutting unit is not in contact with
stones, debris or other foreign objects.
• Switch on the device before approaching
the grass to be cut.
• Avoid over-stressing the device while
working.
• Avoid any contact with fixed obstacles
(rocks, walls, picket fences, etc.). The
nylon line on the spool would wear out
quickly.
• Avoid using the device in bad weather,
especially if there is a danger of lightning!
• Do not try to lock the on/off switch in
place. It must switch off the motor after
releasing the switch.
MT IE NI
Meaning
• Battery is fully
charged
• stand-by (No bat-
tery inserted)
Battery is charging
Battery is overheated
Battery is defective
33
