9 Maintenance and cleaning
9.1.2 iSTM mini for ABIROB
1
1 Protective cap
2 Cover
Fig. 20 Cleaning the iSTM mini for ABIROB
1 Loosen the compressed air hose (5).
2 Unscrew the wire brake (4).
3 Remove the protective cap (1).
4 Pull off the cover (2) over the torch neck.
5 Clean exposed parts with compressed air.
6 Remount the cover (2), protective cap (1) and wire brake (4) with the compressed air hose (5).
9.1.3 iSTM mini for ABIROB
1
1 Torch neck
2 Protective cap
Fig. 21 Cleaning the iSTM mini for ABIROB
1 Remove the ABIROB
2 Remove the protective cap (2) and cover (3).
3 Clean exposed parts of the iSTM mini without the torch, cover, and protective cap (2) with compressed air.
4 Mount the cover (3) and protective cap (2).
5 Remount the ABIROB
EN - 24
®
G with wire brake
2
3 iSTM mini without protective cap and
cover
®
G with wire brake
®
W
3
2
3 Cover
4 iSTM mini without torch neck, cover and protective cap
®
W
®
W torch neck (1).
®
W torch neck (1).
3 4
5
4 Wire brake
5 Compressed air hose
4
