iSTM mini
1 Equip the ABIROB
®
 ABIROB
350 GC instruction leaflet
2 Loosen the cylinder head screw (4).
3 Mount the ABIROB
torch interface.
4 To fix the torch, tighten the cylinder head screw (4) with a max. tightening torque of M = 6 Nm.
NOTICE
• Do not tighten the cylinder head screw (4) unless the welding torch is already mounted.
5 Put the protective cap (2) back on.
6.4 Attaching the ABIROB
1
1 Torch neck
2 Retaining nut
Fig. 16 Attaching the ABIROB
1 Equip the ABIROB
2 Insert the positioning pin (3) in the marked bore.
®
The ABIROB W torch neck (1) may be attached in this position only.
3 Screw the ABIROB
NOTICE
• After repeated use, it may not be possible to loosen the welding torch by hand. A wrench is provided to assist with
loosening.
• Do not use pliers to loosen the welding torch.
BAL.0523.0 • 2019-10-17
®
G torch neck (1) with a tip adaptor, contact tip, and gas nozzle.
®
G torch neck in the welding torch interface. The torch must be inserted all the way into the welding
®
W torch neck
3
2
®
W torch neck
®
W torch neck (1) with a tip adaptor, contact tip, and gas nozzle.
®
W torch neck with retaining nut (2) on to the iSTM mini interface (4).
4
3 Positioning pin
4 iSTM mini
6 Commissioning
EN - 19
