iSTM mini

3.3 Nameplate

The iSTM mini is labeled as follows:
1
1 Protective cap
2 Cover
Fig. 3 Nameplate
When making inquiries, note the following information:
• Device type, device number, certificate of conformity

3.4 Signs and symbols used

The following signs and symbols are used in the operating instructions:
Symbol Description
• Bullet symbol for instructions and lists

Cross-reference symbol refers to detailed, supplementary or further information
1 Step(s) described in the text to be carried out in succession
BAL.0523.0 • 2019-10-17
3
2
4
3 Item number
4 Device type
3 Product description
EN - 7
