4 Scope of delivery
®
iSTM mini for ABIROB W
1 2
1 Protective cap
2 Cover
Fig. 6 Scope of delivery of iSTM mini for ABIROB
• Robot mount for iSTM mini
• Cable assembly for iSTM mini W
• Cover
• Protective cap
• Liner
Tab. 10 Scope of delivery of iSTM mini for ABIROB
*Size and quantity of cylinder head screws depend on robot type.
EN - 10
3 4
3 Cylinder head screw M4 × 16
4 iCAT mini W CAl complete
• 8 cylinder head screws M4 × 12*
• 7 cylinder head screws M4 × 16
• Düsofix silicone-free seal grease, 10 g tin
• Certificate of conformity
• Operating instructions
6
5
5 iSTM mini
6 Cylinder head screw M4 × 12
®
W
®
W
iSTM mini
