iSTM mini

9.1 Maintenance intervals

NOTICE
• The specified maintenance intervals are standard values and refer to single-shift operation.
When using arc welding equipment, always observe the provisions of EN 60974-4 Inspection and testing, as well as any
national laws and regulations.
Check the following:
Several times a day
Clean weld spatter from the torch
head. In the case of heavy weld
spatter build-up, clean during each
welding break.
• Clean the ABIROB
torch cleaning station. Then spray
with ABICOR BINZEL anti-spatter
fluid.
Tab. 13 Maintenance intervals
NOTICE
• We recommend that the iSTM mini is cleaned every three months.
9.1.1 iSTM mini for ABIROB
1
1
Protective cap
Fig. 19 Cleaning the iSTM mini for ABIROB
1 Remove the protective cap (1).
2 Pull off the cover (2) over the torch neck.
3 Clean exposed parts with compressed air.
4 Remount the cover (2) and put on the protective cap (1) again.
BAL.0523.0 • 2019-10-17
Weekly
We recommend basic cleaning once a
week. The type and frequency of
cleaning shall be determined and
established by the operator of the
welding system.
®
torch with a
Optional wire brake
• Clean the wire brake 1–2 times
depending on the quality of the wire
 9.2 Cleaning the wire guide on
page EN-25
®
G
2
2
Cover
®
G
9 Maintenance and cleaning
Monthly
• Check that the connections (cable
assembly, control lead, ground)
are secure. Tighten if necessary.
3
3 iSTM mini without protective cap and cover
EN - 23
