KEB COMBIVERT G6 Installationsanleitung Seite 29

• For 240V rated models:
„Suitable For Use On A Circuit Capable Of Delivering Not More Than 5000 rms Symme-
trical Amperes, 240 Volts Maximum, see instruction manual for Branch Circuit Protection
details"
and
„Suitable For Use On A Circuit Capable Of Delivering Not More Than 18000 rms Symme-
trical Amperes, 240 Volts Maximum when protected by CC, J or RK5 Class Fuses", see
instruction manual for maximum fuse sizes".
• "Integral solid state short circuit protection does not provide branch circuit protection.
Branch circuit protection must be provided in accordance with the Manufacturer Instruc-
tions, National Electrical Code and any additional local codes".
• Wiring terminals are marked to show a range of values or a nominal value of tighte-
ning torque in pound-inches to be applied to the clamping screws as shown below:
Input/Output terminals: 5...7 lb-in
• Use in a Pollution Degree 2 environment.
• "Use 60/75°C Copper Conductors Only"
• "During the UL evaluation, only Risk of Electrical Shock and Risk of Fire aspects were
investigated. Functional Safety aspects were not evaluated"
• In order to comply with CSA C22.2 No. 14-2010 (cUL) following external Input Chokes
need to be installed: See table 1 below!
Table 1: Mains input chokes for CSA applications:
Cat. No. Housing
07G6 A
09G6 A
07G6 A
09G6 A
10G6 A
Branch Circuit Protection for G6 - A Drive series
I) Fuses:
Cat. No. Housing
07G6
09G6
07G6
09G6
10G6
The voltage rating of the external fuses shall be at least equal to the input voltage of the dri-
ves.
Input Voltage [Vac]
240 / 1ph
240 / 1ph
480 / 3ph
480 / 3ph
480 / 3ph
Input Voltage
[Vac]
A 240 / 1ph
A 240 / 1ph
A 480 / 3ph
A 480 / 3ph
A 480 / 3ph
Reactor Cat. No.
in preparation
in preparation
07DRB08-4951
10DRB08-3751
10DRB08-3751
UL248 Fuse rating 600V [A]
Anhang B
FLA Inductance [mH]
3 x 6A 4.88
3 x 8A 3.66
3 x 8A 3.66
Class CC, J or RK5
in preparation
in preparation
6
10
10
D - 29
